3 Cups Anemometer Wind Speed sensor Output Modbus/RS485/Analog/0-5V/4-20mA

Wind speed sensor (Cup Anemometer) Product introduction:

The wind speed sensor adopts the traditional three wind cups wind speed sensor structure, the wind cups choose carbon fiber material, high strength, good start;    the signal processing unit embedded in the cups can output the corresponding wind speed signal according to the user's needs, can be widely used in meteorology, marine, environment, airports, ports, laboratories, industry and agriculture and transportation and other fields.

A three-cup wind speed sensor is a traditional wind speed measurement device commonly used to measure wind speed and monitor meteorological data. The following is a brief introduction of the three-cup wind speed sensor: Structure: The three-cup wind speed sensor usually consists of a stand and three cups, which are evenly distributed on a horizontal platform at an angle of 120 degrees. When the wind blows the cups, the whole structure will rotate.

How it works: When the wind blows over the three-cup wind speed sensor, the wind force causes the cups to rotate. By measuring the speed at which the cups rotate, the wind speed can be calculated. Devices such as tacho sensors or Hall sensors are usually included inside the sensor to detect the speed of rotation of the cups and convert the data into wind speed data.

Accuracy: Three-cup wind speed sensors have a certain degree of accuracy in measuring wind speed within a certain range, and can provide relatively accurate wind speed data.

3 Cups Anemometer wind speed sensor has a wide range of applications in various fields. Here are some common application areas:

1.    Meteorological observations: The wind speed sensor is an essential component of weather stations. It can measure the speed of the wind, providing data for weather forecasting, weather monitoring, and climate research. Weather observation stations, weather satellites, weather radars, and other equipment all use wind speed sensors.

2.    Aviation and aerospace: In the aviation and aerospace fields, understanding the speed of the wind is crucial for flight safety and navigation. Wind speed sensors are used on aircraft, including airplanes, helicopters, and drones, to provide accurate wind speed information for flight planning and operations.

3.    Wind power generation: Wind speed sensors play an important role in the wind power industry. They are used to measure wind speed to determine suitable wind energy resources. This helps optimize the operation and power output of wind turbines and assists wind farm operators in developing effective wind energy utilization strategies.

4.    Fisheries and marine research: In fisheries and marine research, understanding wind speed is important for vessel maneuvering, fishing operations, and oceanographic studies. Wind speed sensors can be used to measure wind speed over the sea surface, guiding vessel navigation and fishing activities, and providing data on wind-driven processes in the ocean.

5.    Construction engineering: Understanding wind speed is crucial for structural design and wind pressure analysis in construction engineering. Wind speed sensors can help engineers assess the impact of wind on buildings to ensure their stability and safety.

6.    Pollution control and environmental monitoring: Wind speed sensors are also used in pollution control and environmental monitoring. By measuring wind speed, the airflow patterns and direction of pollutant dispersion can be understood. This is essential for evaluating air quality, developing pollution control strategies, and monitoring environmental pollution.

Application areas: The three-cup wind speed sensor is commonly used in meteorological observation stations, environmental monitoring stations, wind farms and other places for real-time monitoring of wind speed data and providing important meteorological information support. In addition to the above application areas, wind speed sensors can be used in weather balloons, wind tunnel experiments, HVAC systems, and more. With advancing technology, the application scope of wind speed sensors continues to expand and innovate.

Wind Speed Sensor Datasheet

NBL-W-SS-Wind-Speed-Sensors-Instruction-Manual.pdf
